Penetration Bitumen:

Introduction of Penetration Bitumen and its Applications

The unique feature of Penetrating bitumen produced in Pars Bitumen Company is its easy and vast application in road construction in different environmental conditions. The main purpose of grading bitumen based on penetration is to determine its suitability for use in various industries and conditions. Different grades of bitumen are named according to their hardness level and consistency, and in this way, penetrating bitumen is classified in grades between 30 to 120. These grades are determined based on the penetration depth of the needle.



What is penetrating bitumen?

Penetration Grade Bitumen, supplied by Pars Bitumen Company which is also known as pavement bitumen, is a type of standard bitumen that is usually used in road construction and pavement, and is a petroleum product obtained from the distillation of crude oil.

Penetration bitumen is classified based on their hardness and ability to withstand different traffic and weather conditions. The characteristics of this type of bitumen are determined by its penetration value, which is the depth in millimeters that a standard needle penetrates into the bitumen sample under certain conditions of time, temperature and load.



Penetration bitumen supplied by Pars Bitumen Company is graded based on its penetration value at 25 degrees Celsius, which usually ranges from 10 to 300. The higher the amount of penetration, the softer the bitumen and vice versa. The most common penetrating bitumen grades in road construction and paving are 50/40, 60/70 and 100/80 bitumen grades.

In addition to road construction and paving, penetration bitumen is also used in other applications such as waterproofing, roofing and insulation. This raw material plays a significant role in the development of infrastructure in the construction industry.



The importance of using penetrating bitumen:

In addition, the use of penetrating bitumen supplied by Pars Bitumen Company in road construction projects can also help save energy due to its better efficiency and compatibility with aggregates. This type of bitumen also has better pavement performance and the roads will have a longer useful life.



Knowing the degree of bitumen penetration used in projects allows you to predict the behavior of the desired bitumen in different conditions. For example, bitumen with lower penetration is needed when building roads in hot climates. This helps prevent the asphalt from softening too much at high temperatures.





Importance of quality of penetration Bitumen:

The quality of penetrating bitumen supplied by Pars Bitumen Company is very important for use in road construction industry, paving, waterproofing, roofing and other applications. The quality of this type of bitumen can be evaluated based on different physical and chemical properties. In the following, we mention some important indicators in determining the quality of penetrating bitumen.

The amount of bitumen penetration supplied by Pars Bitumen Company indicates its hardness and resistance to deformation. This penetration rate is measured in tenths of millimeters as the depth a standard needle penetrates into a bitumen sample under specific conditions of time, temperature and load. The amount of bitumen penetration should be within the range specified for its intended use.



Softening point of penetrating bitumen:

Bitumen softening point indicates the temperature at which bitumen becomes soft and flexible. This temperature is also determined through the penetration of a standard needle in bitumen under certain conditions. Bitumen for different applications must have certain conditions and characteristics, and the softening point of penetrating bitumen for the intended application must be within the specified range.



Softening point of penetrating bitumen



Plasticity

Bitumen ductility indicates its elasticity and flexibility. This property is measured in centimeters as the distance a bitumen sample can be stretched without breaking. The ductility of penetrating bitumen should be within the specified range for its intended use.



Solubility of penetrating bitumen

Bitumen solubility indicates its purity and homogeneity. This property of penetrating bitumen is measured by dissolving it in a specific solvent (typically trichloroethylene). Bitumen solubility should be within the range specified for the intended application.



Flash point of bitumen

The flash point of bitumen indicates its safety for handling and storage in different conditions. This characteristic of penetrating bitumen is measured by examining the minimum temperature at which the bitumen produces enough vapor to ignite in a flame. The flash point should also be checked for the intended application.



Specific weight of penetrating bitumen

The specific gravity of bitumen supplied by Pars Bitumen Company indicates its density and consistency, which is measured by examining the ratio of the weight of a certain volume of bitumen to the weight of an equal volume of water. The specific weight of penetrating bitumen should be within the specified range for its intended use.



History of penetrating bitumen

The use of bitumen dates back to ancient times, when this material was used as insulation for sealing boats and buildings. Ancient Babylonians and Egyptians used bitumen as an adhesive and waterproof material in their construction projects. The modern use of bitumen in the construction of roads and paving also dates back to the 19th century. The development of bitumen penetration grading in the 1920s and 1930s was a turning point in the history of bitumen.



Penetration grading provided a standard method for determining the consistency and hardness of bitumen and made it easier to use in road and pavement construction. In the middle of the 20th century, the demand for bitumen increased with construction and the material was used in roofing, waterproofing and other applications. The development of polymer-modified bitumen in the 1960s and 1970s further expanded the range of bitumen applications.



Where is penetrating bitumen used?

Pars Bitumen Penetrating bitumen is usually used in road surfacing projects and industrial projects. This type of standard bitumen is essential for high-quality asphalt pavements and binds the aggregates and contributes to the stability and cohesion of the bitumen mixture. Among all the different grades of penetrating bitumen, the 60/70 grade is one of the most widely used subgrades in road construction projects.

Because 60/70 grade penetrating bitumen provides more strength, it is ideal for high-traffic road asphalt. In addition, this bitumen has a very good performance and works quickly; This means that the roads can be paved and opened quickly.



Bitumen grade 85/100 supplied by Pars Bitumen Company is also common. This penetrating bitumen has a high heat retention property because it can retain heat longer and allows the asphalt to be easily molded into the road. Also, its heat preservation property makes the asphalt not crack even at low temperatures.

Penetration bitumen grade 85/100 is an excellent option for building strong and durable roads in high altitude areas and cold climates.



Applications of penetrating bitumen supplied by Pars Bitumen:



Application of penetrating bitumen in road construction and paving

Penetration-grade bitumen supplied by Pars Bitumen Company is used as an adhesive in asphalt concrete to create a durable and slip-resistant surface for roads, highways, and airports.



Waterproofing and roofing:

Penetration bitumen is used as a waterproofing material for covering roofs, foundations and basements. Also, this type of bitumen can be used as a covering for roofs to protect against weather.



 Adhesives and sealants:

Penetration bitumen is used as an adhesive for gluing insulations, roofing materials and other building materials. This type of bitumen is also used as a sealant for joints and cracks in concrete and masonry.



Covering pipes with penetrating bitumen:

Penetration bitumen supplied by Pars Bitumen Company is used as a coating for pipelines and protection against corrosion and improving the flow of liquids and gases.



Paints and coatings:

Penetrating bitumen is used as a component in paints and coatings to create moisture insulation and resistance to different weather conditions.



Soundproofing:

Penetration bitumen is used as a sound insulation material in buildings, walls and floors to reduce noise and vibration.



Industrial applications of penetrating bitumen

Permeable bitumen is used in various industrial uses such as making roofing materials, asphalt emulsions and adhesives.



What are the properties of penetration grade bitumen produced by Pars Bitumen?

Penetration-grade bitumen or permeation bitumen has a thermoplastic property that softens and hardens depending on the set temperature. Bitumen softens at higher temperatures while it hardens at lower temperatures. The distinct temperature-viscosity relationship of this bitumen is necessary to determine various performance parameters such as the following:



Rheology

stickiness

Durability and durability

Temperature of use



Types of penetration bitumen – different grades of penetration grade bitumen

Types of penetrating bitumen: 1. Grade 10/20 bitumen

10/20 bitumen supplied by Pars Bitumen Company is a heavy bitumen that ensures long-term savings as it can be used to design thinner pavements that reduce asphalt consumption by 30% compared to traditional designs. The degree of penetration of this penetrating bitumen is 10 to 20 and its softening point is between 58 and 66 degrees Celsius. This type of bitumen is a normal bitumen that is suitable for road construction and repairs and asphalt paving. This bitumen grade is mainly used in making hot mix asphalts.

Penetrating bitumen 10/20 is used for hot mix asphalt due to its very strong viscosity compared to other grades.



Types of bitumen penetration degree: 2. 20/30 grade bitumen

20/30 grade bitumen supplied by Pars Bitumen has a hard penetration degree and is used as bitumen for pavement, which is suitable for road construction or road construction repair. Also, this penetrating bitumen grade is used to produce asphalt pavements with technical specifications.



Types of penetrating bitumen: 3. 30/40 grade bitumen

30/40 grade bitumen is a semi-hard penetrating bitumen that is suitable as pavement bitumen or for road construction and repair. This penetrating bitumen grade supplied by Pars Bitumen Company is also suitable for the production of asphalt pavements. Penetration bitumen have thermoplastic properties that make them soft at high temperatures and hard at low temperatures.



Pars Bitumen 30/40 is used in making hot asphalt for foundations and road infrastructure. This penetrating bitumen grade is one of the most widely used bitumen grades and a basic material for other bitumen products.



Types of bitumen penetration degree: 4. 40/50 grade bitumen

This penetration bitumen grade is used in tropical areas with hot weather due to its blowing and high air penetration. This grade is mainly used in the construction of warm asphalt for road infrastructure. In fact, 40/50 penetration bitumen means that the amount of penetration in standard conditions that is usually used as a pavement is in the range of 40 to 50.

This type of bitumen supplied by Pars Bitumen is suitable for road construction projects in hot and dry areas, and in addition, it can be used to produce a type of asphalt primer. Also, bitumen with a penetration degree of 50/40 is used in road construction, paving and some industrial uses and in the production of asphalt mixture, bitumen emulsion, cutback bitumen and modified bitumen.



Types of penetrating bitumen: 5. 60/70 grade bitumen

Pars Bitumen penetration degree of 60/70 means that the amount of penetration in standard conditions is in the range of 60 to 70 and is classified as semi-hard bitumen. This bitumen grade is mainly used for warm mixes, especially in moderate weather conditions. This penetrating bitumen grade is also used to make bitumen emulsion, cutback bitumen and modified bitumen grades.

Types of penetrating bitumen: 6. Bitumen penetration degree 60/90

60/90 bitumen supplied by Pars Bitumen is classified into BND (road bitumen) and BN (petroleum bitumen). BND bitumen has good adhesion to different stone materials and their flexibility is high at low temperatures and they are resistant to weather effects. BND 60/90 bitumen is used for road infrastructure in hot climate areas, preparation of hot asphalt and bituminous mixtures in hot climate areas.



60/90 grade penetrating bitumen can also be used to produce asphalt ester and waterproofing products.



Types of penetrating bitumen: 7. 80/100 grade bitumen

Bitumen grade 80/100 manufactured in Pars Bitumen Company has a standard penetration degree and it is usually used as pavement bitumen in road construction and other industrial projects. This penetrating bitumen grade is mainly used in making warm asphalts for foundations, especially in cold climates.



80/100 penetration grade bitumen produced in Pars Bitumen is suitable for road construction projects in cold regions and it is also used to produce asphalt mixtures, cutback bitumen and modified bitumen.





The price of penetrating bitumen:

The price of penetrating bitumen supplied by Pars Bitumen Company can vary according to various factors such as bitumen grade, purchase amount, transportation costs, packing type and etc. The price of this type of bitumen in Pars Bitumen is also calculated based on the exchange rate, so it is not possible to determine an exact price for it.



Prices can also vary by region and country. However, the quality of bitumen is very important and it is better to ensure the quality of bitumen from the desired supplier such as Pars Bitumen before buying penetrating bitumen.



Buy penetrating bitumen

In this article, we talked about Penetration Grade Bitumen, which is one of the most common types of bitumen used in road construction. It is a petroleum bitumen and is produced in various viscosities through fractional or vacuum distillation of crude oil. This refinery bitumen consists of a wide range of bitumen, each of which is different in terms of hardness; That is, the lower the grade, the harder the bitumen.



To know the price of penetrating bitumen and to get more information and to buy penetrating bitumen, be in touch with Pars Bitumen Company.

Written and Gathered by Pars Bitumen Company
